Edge SPCEL02P
Robust Industry PC with VESA/DIN-Rail mount and various options with PoE function
The Shuttle Edge PC SPCEL02P is a fanless IPC barebone in a robust 450 ml metal chassis and intended for DIN-Rail or VESA mounting. It is flexible in use and designed for maintenance-free 24/7 operation at ambient temperatures of up to 40°C. Inside there is an Intel Celeron "Elkhart Lake" processor with slots for RAM module, M.2 SSD card and WLAN card. The small housing offers an amazing variety of connections, including dual LAN, COM port and Digital I/O. Power is supplied either via the DC input or via a network cable using the PoE function. This product is targeted at professional applications such as edge computing (IoT gateway), automation, digital signage, control, data logging and video surveillance.

Intel Celeron J6412 Processor
75 × 120 × 51 mm (DWH)
Up to 32 GB DDR4 memory (SO-DIMM)
Two M.2 slots (1× M.2-2280, 1× M.2-2230)
2× 2.5 Gbit Ethernet, Wi-Fi optional
2× USB 3.2 (10 Gbit), 1× COM, DIO
1× M.2-SSD
Suitable for 12 to 24 V DC
DIN rail/wall/VESA mounting option
PoE function
