MSI WindBOX MS-C907 / N97

MSI WindBOX MS-C907 / N97

MS-C907
Compact-Size Box PC with Intel® IOTG Alder Lake-N Processor for Ultra Low-Power Fanless Solution
Intel® Alder Lake-N PC Client Series SoC
DDR5 4800 MHz SODIMM Slot up to 16GB
Dual independent displays: DP, HDMI
2 2.5 GbE LAN with RJ-45
1 M.2 B Key, 1 M.2 E Key Slot
SATA 3.0 for storage(2.5” SSD/HDD)
2 USB 3.2 Gen 2, 2 USB 3.2 Gen 1, 6 USB 2.0, 2 COM (1 RS-485), GPIO, Audio, Amplifier-6W
2 COM or 2 CANbus (Option by M.2 Module)
4 opening reserved for antennas
Anti-Vibration & Shockproof Design to Compliance IEC 61373
Wide Voltage DC-IN 9~36V
Ultra-Compact with fanless design

Intel® IOTG Alder Lake-N Processor N97, QC, 12W
Single Channel DDR5 4800 MHz Up to 16GB
Intel® UHD Graphics
HDMI up to 3840 x 2160 @30Hz
DP up to 4096 × 2304 @60Hz
2 x Intel® I225-V 2.5 GbE LAN
bit (4*GPI; 4*GPO), 5V
DC-in 9~36V with Lockable DC Jack
200 x 150 x 55 mm
