Giada F106D Intel® Celeron N5100

Giada F106D Intel® Celeron N5100

Intel® Jasper Lake Processors
The booksize player is equipped with Jasper Lake processors, including the Celeron® N5100 (TDP 6W, 1.1Ghz base frequency) and higher-performance Celeron® N5095 (TDP 15W, 2.0Ghz base frequency).

Supporting Dual Display Outputs
The player adopts Intel® UHD Graphics and supports vivid dual 1080p video playback. Its HDMI 2.0a and DisplayPort 1.2 ports can also support resolutions up to 4096 x 2160@60Hz.

Fanless Design
With a passive thermal cooling system, the fanless design reduces the failure rate and makes the device running with noise-free and dustproof. It enables this Giada® device applicable in mission critical applications.

Intel® Celeron® N5100 processor
8Gb Onboard LPDDR4-2666 MHz
1 x M-Key M.2 (2242/2280) for SSD (only PCIe SSD)
1 x Full-size Mini-PCIe for MSATA
Intel® UHD Graphics
1 x DP (Max.4096 x 2160 @60Hz)
1 x HDMI (Max.4096 x 2160 @60Hz)
189.6mm x 148.3mm x 26mm (7.46” x 5.83” x 1.02”)
