Active Cooler Intel LGA

Active Cooler Intel LGA

COOLER
F5000-C12
Motherboard Accessories
Copper base with two heatpipes and aluminium fins,
plastic cover for optimized airflow
Specific heatsink (heatpipe/fan) designed for 35 W TDP
Spring-loaded mounting screws for specified downforce

DIMENSIONS 143.5 mm x 61.5 mm x 20.5 mm
WEIGHT ~150 g
RECOMMENDED MOUNTING
TORQUE FOR HEATSINK
SCREWS
0.6 Nm (max. 0.8 Nm)
INTEGRATED DC FAN PWM-controlled, Two Ball Bearing
OPERATING VOLTAGE 5 V
POWER CONSUMPTION max. 3 W
DIMENSIONS 60 x 15 mm
FAN SPEED max. 6.300 rpm +/- 10 % @ 100 % PWM
NOISE LEVEL max. 53 dbA
FAN CABLE LENGTH 50 mm
FAN CONNECTOR/HOUSING M125H or equivalent
MTBF 50.000 hrs @ 40 °C
