PB MSI ITX MS-9892 / E3940 Normal Temp

PB MSI ITX MS-9892 / E3940 Normal Temp

Mini-ITX with Intel® Apollo Lake/Apollo Lake-I for Fanless, Low-Power, High-Performance & Wide Temperature Solution
Intel® Apollo Lake/Apollo Lake-I Series SoC
2 DDR3L 1866 MHz SODIMM slots up to 8GB
Triple independent displays : DP, HDMI, LVDS/eDP
2 GbE LAN with RJ-45
1 PCIe x1 (Gen 2), 1 Mini-PCIe (Full/Half size, with SIM Holder), 1 Mini-PCIe (Full size, with mSATA) slots
mSATA, 2 SATA 3.0 for storage
4 USB 3.2 Gen 1, 6 USB 2.0, 6 COM (2 RS-485), GPIO, PS/2, Audio, S/PDIF, System FAN
Onboard TPM 2.0
SMBus, Chassis Intrusion
Wide operating temperature : -40~85°C (by option)
Wide Voltage DC-IN 12~24V

Intel® Atom™ x5 Processor E3940, QC, 9W
2 x 204-pin SO-DIMMs Up to 8 GB
Intel I211-AT GbE LAN
6 x USB 2.0 (internal)
4 x USB 3.2 Gen 1 (rear)
6 x COM (6 x Internal)
DC-in 12V~24V
170 x 170mm (Mini-ITX)
