MB Kontron SBC-EKL Atom® x6425RE

MB Kontron SBC-EKL Atom® x6425RE

3.5"-SBC-EKL is a 3.5" single board computer powered by Intel® Atom® x6000E Series, Celeron® J6000 / N6000 Series and Pentium® J6000 / N6000 Series processors. Besides great performance improvement in graphics, it features 2.5 GbE with TSN (Time Sensitive Networking) capability and enhanced TPM 2.0 security / encryption support, ideal for a variety of IoT applications, such as industrial automation, retail, smart city and healthcare.

The board supports an extended B2B connector, providing additional I/O port expansion to fulfill possible application requirements.

3.5″ SINGLE BOARD COMPUTER WITH INTEL® ATOM® X6000E SERIES, CELERON® J6000 / N6000 SERIES & PENTIUM® J6000 / N6000 SERIES PROCESSORS
SPECIFICATIONS
2x DP, 1x LVDS for video output
2x 2.5 GbE LAN for Ethernet
2x USB 3.2 Gen 2, 6x USB 2.0, 2x RS232/422/485, 2x CAN Bus, 8x DIO for peripherals
1x SATA 3.0, 1x M.2 Key B, 1x M.2 Key E, 1x M.2 Key M for storage & expansion
1x B2B Connector for extended I/Os: 2x PCIe x2, SM Bus, I2C, UART, GSPI & DDI (optional)
