IB4-271
Long Life Cycle Intel Elkhart Lake Platform Thin Mini-ITX Motherboard

Intel Elkhart Lake Processors
Long Product Life Cycle
Giada IB4-271, a thin Mini-ITX motherboard, adopts Elkhart Lake Celeron J6412 with TDP of 10W. The motherboard is based on Intel® IOTG roadmap with 7+ years' lifespan. The Elkhart Lake platform has up to 1.7x improvement in single-thread performance and up to 1.5x improvement in multi-thread performance generation over generation.

With 3 Display Outputs
Supporting 4K Resolution
The motherboard has three display outputs, including a DP, an HDMI and a LVDS ports. Adopting Intel® UHD Graphics, the motherboards supports 4K display via the HDMI (4096 x 2160 @60 Hz) and DP (4096 x 2160 @60 Hz) ports.

Supporting Wi-Fi 6
With Wi-Fi 5/6 support, Giada IB4-271 offers lightning-fast data transfer speeds and seamless connectivity to a wide range of peripherals. Whether you need to connect multiple high-resolution displays or transfer large files quickly, the Giada motherboard has got you covered.

Fanless Design
With a passive thermal cooling system, the fanless design reduces the failure rate and makes the device running with noise-free and dustproof. It enables this Giada® motherboard applicable in mission critical applications.

Intel® Celeron® J6412 processor
2 x USB3.2 Gen2 (10 Gbps), 2 x USB2.0
1 x HDMI (Max.4096 x 2160 @60 Hz)
1 x DP (Max.4096 x 2160 @60 Hz)
2 x Realtek RTL 8111H Gigabit Ethernet
DC-IN, 12~24 V
Thin Mini-ITX, 170 mm x 170 mm (6.69” x 6.69”)
