MSI WindBOX MS-C909 / J6412

MSI WindBOX MS-C909 / J6412

MS-C909
Compact-Size Box PC with Intel® Celeron® Elkhart Lake J6412 Processor for Ultra Low-Power Fanless Solution
Intel® Celeron® Elkhart Lake J6412 SoC
DDR4 3200 MHz SODIMM Slot up to 16GB
Dual independent displays: 2 HDMI
1 2.5 GbE LAN with RJ-45
1 M.2 B Key, 1 M.2 E Key Slot
4 USB 3.2 Gen 1, 1 COM, GPIO
2 opening reserved for antennas
Anti-Vibration & Shockproof Design to Compliance IEC 61373
Wide Voltage DC-IN 12~24V
Ultra-Compact with fanless design
Optional InnoAgent Remote Management Module (Remote Power On/Off/Reset, 6 bit-Programmable Remote control GPIO, In-Band Heartbeat Agent to Check Device, support iCAP 2.0 Private Cloud)

Intel® Celeron® Processor J6412, QC, 10W
Single-Channel DDR4 3200 MHz Up to 16 GB
Intel® UHD Graphics
HDMI up to 3840 x 2160 @30Hz
1 x Intel® I226-V 2.5 GbE LAN
4 x USB 3.2 Gen 1
COM1: RS-232/422/485, 0V/5V/12V
8-bit (4 x GPI; 4 x GPO), 5V
130 x 155 x 40 mm
